Clean-Flush® Aircraft Toilet Externally Serviced Toilet Systems

Externally Serviced Toilet System Models

Externally-serviced models offered by Aircraft Technologies include two models with a unique design that sets these systems apart from others on the market. Made of tough molded plastic and composite materials for maximum strength-to-weight ratio, these Series 90 systems are easy to install and service, and economical to maintain.

Model 9055

21.0 pounds (dry)

3-gallon waste capacity

18.75″ W, 16.5″ D, 11″ H

Model 9060

21 pounds (dry)

4-gallon waste capacity

18.75″ W, 16.5″ D, 13.75″ H

Minimally Intrusive Installation

The Series 90 externally serviced toilet systems are designed for economical installation in all corporate aircraft. The service lines between the toilet and the external service panel are only 3/4″ in diameter for the waste dump line and 1/2″ for the flushing reservoir charge line.

Built-in Macerator

A macerator within the toilet breaks down waste and pumps it to the service cart outside the aircraft. The smaller line carries fresh flushing fluid to the reservoir from the Ground Service Cart

Construction

It has double sealed protection against leakage and meets FAR 25.853(a) self-extinguishing specifications.

Odor Control

The Series 90 waste compartments are closed when the toilets are not in use. Additionally, each model has provisions for positive overboard venting. We recommend Clean-Flush® additives for the utmost in odor control.

Guarantee

All aircraft toilets carry a one year guarantee against defects in workmanship and materials.

Lightweight & Portable
A lightweight, portable, self-contained service cart featuring the necessary components to service the Series 90 toilets is available.
